Mid Rail Tee Key Clamp Fitting 42.4mm - A22

The A22 is the mid rail tee for an intermediate post: the post runs straight through the fitting and the rail is picked up against it at 90 degrees, part way up the run.

Long straight runs of guarding are where it earns its keep. The top rail is carried by the fittings at the head of each post, and the A22 does the same job lower down for the knee rail, mid rail or kick rail, without interrupting the post. On a factory walkway or a yard barrier you will use several per post line, all set to the same height, which is what gives the finished run its level horizontal lines.

Specification

• Type code A22, mid rail tee for 90 degree connections
• Post passes through the fitting so intermediate uprights stay unbroken
• Suits 42.4mm outside diameter steel tube
• Galvanised finish, weatherproof for internal or external use
• Bolt together key clamp construction, no welding on site
• Part of our modular key clamp handrail and guarding system
• Powder coating available on request

Fitting note: thread every A22 onto its post before the top fittings go on, and run a line or a laser along the post line to get all the mid rails at a matching height.
